Power Group 181
Table 8-7. Voltage Probe Discrete Reading
Variable Name:
DellVoltageDiscreteReading
Data Type: Integer
Possible Data Values Meaning of Data Value
voltageIsGood(1) The voltage probe discrete reading is good.
voltageIsBad(2) The voltage probe discrete reading is bad.
Table 8-8. Amperage Probe Definitions
Variable Name:
DellAmperageType
Data Type: Integer
Possible Data Values Meaning of Data Value
amperageProbeTypeIsOther(1) The amperage probe type is
not one of the following:
amperageProbeTypeIsUnknown(2) The amperage probe type is
unknown (not known or
not monitored).
amperageProbeTypeIs1Point5Volt(3) The amperage probe type is a
1.5-ampere (A) probe.
amperageProbeTypeIs3Point3volt(4) The amperage probe type is a
3.3-A probe.
amperageProbeTypeIs5Volt(5) The amperage probe type is a
5-A probe.
amperageProbeTypeIsMinus5Volt(6) The amperage probe type is a
–5-A probe.
amperageProbeTypeIs12Volt(7) The amperage probe type is a
12-A probe.
amperageProbeTypeIsMinus12Volt(8) The amperage probe type is a
–12-A probe.
amperageProbeTypeIsIO(9) The amperage probe type is an
I/O amperage probe.
amperageProbeTypeIsCore(10) The amperage probe type is a
core amperage probe.
