Power Group 179
acOutOfRangeButPresent(32) The power supply’s AC power is present, but
it is out of range.
configurationError(64) The power supply sensor detects a
configuration error.
Table 8-5. Power Supply Configuration Error Type
Variable Name:
DellPowerSupplyConfigurationErrorType
Data Type: Integer
Possible Data Values Meaning of Data Value
vendorMismatch(1) The power supply configuration error type is
vendor mismatch.
revisionMismatch(2) The power supply configuration error type is
revision mismatch.
processorMissing(3) The power supply configuration error type is
processor missing.
Table 8-6. Voltage Probe Type
Variable Name:
DellVoltageType
Data Type: Integer
Possible Data Values Meaning of Data Value
voltageProbeTypeIsOther(1) The voltage probe type is not one of the
following:
voltageProbeTypeIsUnknown(2) The voltage probe type is unknown
(not known or not monitored).
voltageProbeTypeIs1Point5Volt
(3)
The voltage probe type is a 1.5-volt (V)
probe.
Table 8-4. Power Supply Sensor State
(continued)
Variable Name: DellPowerSupplySensorState
Data Type: Integer
Possible Data Values Meaning of Data Value
