Power Group 177
onlineAndFanFailure(10) The power supply is online and indicating that its
fan is not working.
powerSupplyIsON(16) The power supply is indicating that it is on.
powerSupplyIsOk(32) The power supply is indicating that it is OK.
acSwitchIsON(64) The power supply is indicating that the AC power
switch is on.
onlineandAcSwitchIsON
(66)
The power supply is online and indicating that the
AC power supply switch capability is activated.
acPowerIsON(128) The power supply is indicating that the AC power
is on.
onlineAndAcPowerIsON
(130)
The power supply is online and indicating that the
AC power is on.
onlineAndPredictiveFail
ure(210)
The power supply is online and indicating that it
has a problem.
acPowerAndSwitchAreOn
PowerSupplyIsOnIsOkAnd
Online(242)
The power supply is online and OK.
Table 8-3. Power Supply Type Definitions
Variable Name:
DellPowerSupplyType
Data Type: Integer
Possible Data Values Meaning of Data Value
powerSupplyTypeIsOther(1) The power supply type is not one of
the following:
powerSupplyTypeIsUnknown(2) The power supply type is unknown
(not known or not monitored).
powerSupplyTypeIsLinear(3) The power supply type is a linear
power supply.
Table 8-2. Power Supply State Settings Unique
(continued)
Variable Name: DellPowerSupplyStateSettingsUnique
Data Type: Integer
Possible Data Values Meaning of Data Value
