116 Chassis Information Group
Table 5-22. Firmware Type
Variable Name:
DellFirmwareType
Data Type: Integer
Possible Data Values Meaning of Data Value
other(1) The firmware type is other than
following values.
unknown(2) The firmware type is unknown.
systemBIOS(3) The firmware type is System BIOS
embeddedSystemManagementContro
ller(4)
The firmware type is Embedded
System Management Controller.
powerSupplyParallelingBoard(5) The firmware type is Power Supply
Paralleling Board.
systemBackPlane(6) The firmware type is System
(Primary) Backplane.
powerVault2XXSKernel(7) The firmware type is Dell™
PowerVault™ 2XXS Kernel.
powerVault2XXSApplication(8) The firmware type is PowerVault
2XXS Application.
frontPanel(9) The firmware type is Front Panel
Controller.
baseboardManagementController
(10)
The firmware type is Baseboard
Management Controller.
hotPlugPCI(11) The firmware type is Hot Plug
Peripheral Component Interconnect
(PCI) Controller.
sensorData(12) The firmware type is Sensor Data
Records.
peripheralBay(13) The firmware type is Peripheral Bay
Backplane.
secondaryBackPlane(14) The firmware type is Secondary
Backplane for ESM 2 systems.
secondaryBackPlaneESM3And4(15) The firmware type is Secondary
Backplane for ESM 3 and 4 systems.
