Chassis Information Group 115
Table 5-20. System Properties
Table 5-19. NMI Button Control Settings
Variable Name:
DellNMIButtonControlSettings
Data Type: Integer
Possible Data Values Meaning of Data Value
none(0) The NMI button has no settings capabilities.
unknown(1) The NMI button settings are unknown.
enabled(2) The NMI button state is enabled.
disabled(4) The NMI button state is disabled.
Variable Name:
DellSystemProperties
NOTE:
These values are bit masks, so combination values are possible.
Data Type: Integer
Possible Data Values Meaning of Data Value
none(0) No properties.
energySmart(1) The system is an Energy Smart System.
Table 5-21. Chassis System Class
Variable Name: DellChassisSystemClass
Data Type: Integer
Possible Data Values Meaning of Data Value
other(1) The chassis system class is not one of the following:
unknown(2) The chassis system class is unknown.
workstationClass(3) The chassis system class is a workstation.
serverClass(4) The chassis system class is a server.
desktopClass(5) The chassis system class is a desktop.
portableClass(6) The chassis system class is a portable.
netPCClass(7) The chassis system class is a "Net PC."
storageClass(8) The chassis system class is storage.
