Chassis Information Group 105
Chassis Information Group Variable Values
This section includes definitions for server administrator-specific variable
values used in this section.
Table 5-1. Log Format
Variable Name:
DellLogFormat
Data Type: Integer
Possible Data Values Meaning of Data Value
raw(1)
The log is in the format received from the
firmware.
ascii(2) The log is in ASCII format.
uniCode(3) The log is in Unicode format.
Table 5-2. Chassis Type
Variable Name: DellChassisType
Data Type: Integer
Possible Data Values Meaning of Data Value
other(1) The chassis type is not one of the following:
unknown(2) The chassis type is unknown.
desktop(3) The chassis type is a desktop.
lowProfileDesktop(4) The chassis type is a low-profile desktop.
pizzaBox(5) The chassis type is a pizza box.
miniTower(6) The chassis type is a minitower.
tower(7) The chassis type is a tower.
portable(8) The chassis type is a portable.
lapTop(9) The chassis type is a laptop.
noteBook(10) The chassis type is a notebook.
handHeld(11) The chassis type is a handheld.
dockingStation(12) The chassis type is a docking station.
allInOne(13) The chassis type is an all-in-one.
