Remote Access Service 87
Adding and Configuring DRAC III Demand Dial-Out Entries
NOTE: You must have Admin privileges in Server Administrator to use the Remote Access Service.
If you set the dial-in (PPP) setting to Preset, the demand dial-out entry causes the Remote Access
Service to disconnect and call the management station back at a preset number. Upon callback, you must
provide your DRAC user authentication to access the Remote Access Service.
NOTE: The DRAC managed system software uses a PPP connection to talk to the installed DRAC. The IP address for
this PPP connection is 192.168.234.235. It is possible that this network IP address could already be in use by other
systems or applications. If this situation occurs, the PPP connection fails to operate. If this address is already in use, the
user is required to change the managed-system PPP client IP address to a different number. To change the
managed-system PPP server IP address to use another network so that conflicts do not occur, you must use the racadm
utility. See the Dell Remote Access Controller Racadm User's Guide for information about using the racadm utility.
To add a demand dial-out entry, perform the following steps:
1
On the Server Administrator home page, click the
Main System Chassis
object, and then click the
Remote Access
object.
2
Click the
Configuration
tab.
3
Select
Demand Dial-Out
.
4
Click
Add
.
5
Enter the management station IP address that the Remote Access Service calls back when called by
this user.
6
Enter the phone number used by the system's modem in the
Phone Number
field.
7
Enter the user name for the demand dial-out user in the
User Name
field.
8
Enter the password for the demand dial-out user in the
Password
field.
9
Select a setting from the
Authentication
drop-down menu:
•
Any
— Allows the connection using any type of encryption, including no encryption
•
Encrypted
— Requires the connection to use some type of encryption
•
CHAP
— Requires the connection to use the CHAP
10
Click
Apply Changes
and click
OK
to save your changes.
Configuring the DRAC III Modem Settings
NOTE: You must have Admin privileges in Server Administrator to use the Remote Access Service.
If your DRAC III kit includes the optional PCMCIA modem, you must configure the modem prior to use.
To configure the DRAC III modem, perform the following steps:
1
On the Server Administrator home page, click the
Main System Chassis
object, and then click the
Remote Access
object.
2
Click the
Configuration
tab.
3
Click
Modem
.
