Quick Reference Guide

Quick Start 25
4. Select the interfaces you want to monitor by clicking Add in the top right corner of the screen. A
selection screen appears, when you do. You must typically select a device in the upper panel,
then select at least one interface in the lower one. You can multi-select by left-clicking while
holding down the Ctrl key.
5. In the Thresholds screen, examine existing thresholds by clicking on the listed threshold in the
upper panel, then clicking
Edit. For example BW Util (utilized bandwidth) has thresholds at 90%
(High, Critical), 80% (Medium, Warning), and 0% (Low, Cleared). When the data crosses
thresholds, the monitor reacts.
Available attributes depend on the type of monitor you are creating. Notice that if you click
Edit
in the upper
Attribute panel, you can alter whether crossing this threshold emits a notification (an
alarm that would appear on the
Alarm Panels ), the type of calculation, and so on. You can even
alter existing thresholds, by selecting one, then clicking
Edit to the right of the selected
threshold.
For the sake of this monitor, we will only examine these capabilities, not alter any thresholds.
Click
Cancel (twice) to return this screen to its original appearance.
NOTE:
If a threshold’s counter is an SNMP Counter32 (a 32-bit counter) monitoring can
exceed its capacity with a fully utilized gigabit interface in a relatively short period
of time. The defaults configured in this monitor account for this, but if you know
that this is an issue, you can probably configure the monitor to account for it too.
After taking a look at Thresholds no more configuration is required. Notice, however, that you
can also configure
Metrics on another screen in this editor to calculate additional values based on
the monitored attributes. Consult online help for more information about the other screens and
their capabilities.
6. Click Save and the monitor is now active.
Notice that the
Availability icon appears at the top of this screen in the monitor’s row to indicate
a responding monitor. When you select the monitor, that same icon appears for each interface
you selected in the detail panels in the lower part of the screen. Click on an interface in the
Monitor Status Summary detail panel, and the attribute values for that device appear in the lower
half of the detail panel.
Show Performance
The action -> Show Performance menu item in Alarm Manager, Inventory Manager and Topology
Map displays an automatically assembled dashboard. When you select this command OpenManage
Network Manager finds all of the performance attributes being monitored for the selected equipment
and creates a dashboard with one component for each attribute.
