1. In OMIMSSC, do any of the following to open an Operational Template:
● In the OMIMSSC dashboard, click Create Operational Template.
● In the navigation pane, click Profiles > Operational Template, and then click Create.
The Operational Template wizard is displayed.
2. Enter a name and description for the template.
3. Select the type of device, and enter the IP address of reference device, and then click Next.
NOTE: You can capture the configuration of reference server with iDRAC 2.0 and later.
4. In Device Components, click a component to view the available attributes and their values.
The components are as follows:
● Firmware update
● Hardware components, which are RAID, NIC, and BIOS.
NOTE: In iDRAC Embedded 1 component, following are the privileges and their values for User Admin Privilege
attribute.
Table 9. Privilege value table
Value Privilege
1 Login
2 Configure
4 Configure Users
8 Logs
16 System Control
32 Access Virtual Console
64 Access Virtual Media
128 System Operations
256 Debug
499 Operator Privileges
● Operating system—select either Windows, or ESXi, or RHEL.
5. Use the horizontal scroll bar to locate a component. Select the component, expand a group, and then edit its attribute
values. Use the vertical scroll bar to edit a groups and attributes of a component.
6. Select the check box against each component, because, the configurations of selected components are applied on the
managed device, when the Operational Template is applied. However, all the configurations from the reference device are
captured and saved in the template.
NOTE:
Irrespective of the selection made in the check box against each component, all the configurations are captured
in the template.
In Operating System component, perform the steps in either of the following options, as per your requirement:
● For Windows operating system deployment on SCCM, see Windows component for the OMIMSSC console extension for
SCCM.
● For Windows operating system deployment on SCVMM, see Windows component for the OMIMSSC console extension
for SCVMM.
● OMIMSSC
● For non-Windows operating system deployment, see Non-Windows component for the OMIMSSC console extensions.
7. To save the profile, click Finish.
