Table 9. Virtualization events (continued)
Event name Description Severity Recommended action
Dell-Power supply sensor detected a non-
recoverable value
A power supply
sensor in the
specified system
detected an error
from which it cannot
recover
Error No action
Dell-Memory Device Status warning A memory device
correction rate
exceeded an
acceptable value
Warning No action
Dell-Memory Device error A memory device
correction rate
exceeded an
acceptable value, a
memory spare bank
was activated, or a
multibit ECC error
occurred
Error Put the system into maintenance mode
Dell-Fan enclosure inserted into system Sensor returned to
normal value
Info No action
Dell-Fan enclosure removed from system A fan enclosure has
been removed from
the specified system
Warning No action
Dell-Fan enclosure removed from system
for an extended amount of time
A fan enclosure has
been removed from
the specified system
for a user-definable
length of time
Error No action
Dell-Fan enclosure sensor detected a non-
recoverable value
A fan enclosure
sensor in the
specified system
detected an error
from which it cannot
recover
Error No action
Dell-AC power has been restored Sensor Returned to
Normal Value
Info No action
Dell-AC power has been lost warning An AC power
cord has lost
its power, but
there is sufficient
redundancy to
classify this as a
warning
Warning No action
Dell-An AC power cord has lost its power An AC power
cord has lost its
power, and lack of
redundancy requires
this to be classified
as an error
Error No action
Dell-Processor sensor returned to a normal
value
Sensor Returned to
Normal Value
Info No action
Dell-Processor sensor detected a warning
value
A processor sensor
in the specified
Warning No action
