Table 9. Virtualization events
Event name Description Severity Recommended action
Dell-alertTemperatureProbeReadWarning Unable to
read Temperature
Sensors
Warning No action
Dell-alertTemperatureProbeChangeFailure Temperature
increase Error
Critical Check the chassis event log for fan
issues and fix any issues present. If fan
issues are not detected, check chassis
ambient temperature and make sure the
temperature is within operating range. To
check the chassis ambient temperature,
run the following RACADM command:
racadm getsensorinfo.
Dell-Current sensor detected a warning
value
A current sensor
in the specified
system exceeded its
warning threshold
Warning No action
Dell-Current sensor detected a failure value A current sensor in
the specified system
exceeded its failure
threshold
Error Put the system into maintenance mode
Dell-Current sensor detected a non-
recoverable value
A current sensor in
the specified system
detected an error
from which it cannot
recover
Error No action
Dell-Redundancy regained Sensor Returned to
Normal Value
Info No action
Dell-Redundancy degraded A redundancy sensor
in the specified
system detected
that one of the
components of the
redundancy unit has
failed but the unit is
still redundant
Warning No action
Dell-Redundancy lost A redundancy sensor
in the specified
system detected
that one of the
components in the
redundant unit has
been disconnected,
has failed, or is not
present
Error Put the system into maintenance mode
Dell-Power supply returned to normal Sensor returned to
Normal Value
Info No action
Dell-Power supply detected a warning A power supply
sensor reading in
the specified system
exceeded a user
definable warning
threshold
Warning No action
Dell-Power supply detected a failure A power supply has
been disconnected
or has failed
Error Put the system into maintenance mode
