"id": "[vCenter: jpvc7dot0d5-2.sped.bdcsv.lab][Cluster: R6415_vSAN_AllFlash_ESXi7.0RC+]
[Host: 100.100.10.154][Update PreCheck Task] System Lockdown Mode is turned On for iDRAC
IP, 172.20.5.5; hence Firmware update cannot continue."
}
],
"status": "ERROR"
}
],
"status": "ERROR"
},
{
"host": "host-19",
"type": "HOST",
"check_statuses": [],
"status": "OK"
},
{
"host": "host-13",
"type": "HOST",
"check_statuses": [],
"status": "OK"
},
Remediate cluster
Command: POST https://{{VC IP/FQDN}/}}/api/esx/settings/clusters/{cluster ID}/software?vmw-task=true&action=apply
{
"accept_eula" : true
}
Description: Applies the desired state associated with the given cluster to hosts within the cluster.
HTTP response codes: 200. For the list of all the response codes, see Response codes on page 172.
Example response:
{task-id}
Set up blink indicator light
To help in locating a physical server in a large data center environment, you can set the front indicator light to blink for a set
time period.
1. To launch the Blink Server LED Indicator wizard, perform either of the following actions:
a. On the OMIVV home page, expand Menu, select Hosts and Clusters, right-click a host or cluster, and then go to
Summary > OMIVV Host Information > Host Actions > Blink Server LED Indicator.
b. Right-click a host, go to OMIVV Host Actions > Blink Server LED Indicator.
2. In the right pane, click Summary, and then go to OMIVV Host Information > Hosts Action > Blink Server LED
Indicator.
The Blink Server LED Indicator dialog box is displayed.
3. Select any one of the following:
a. To turn on the server LED indicator and set the time period, click On.
b. To turn off the server LED indicator, click Off.
Configure System Lockdown Mode
The System Lockdown Mode is supported only for iDRAC9-based servers with an Enterprise license. When you turn on the
System Lockdown Mode, lock the system configuration including firmware updates. The System Lockdown Mode setting is
intended to protect the system from unintentional changes. You can turn on or turn off the System Lockdown Mode for
Host Management
141
