b. If you have issues while updating the firmware, select the Delete Job Queue and Reset iDRAC check box. This may
result in successful completion of the update process. This increases the overall update time that is required for job
completion, cancels any pending jobs or activities that are scheduled on the iDRAC, and resets the iDRAC.
For hosts managed using chassis credential profile, delete job queue is not supported.
8. Under the Update Schedule section, select any one of the following options:
● Update Now
● Schedule Update
9. On the Review Summary page, review the firmware update information, and then click FINISH.
The firmware update jobs can take up to several hours depending on the components and number of servers selected. You
can view the status of the jobs on the Jobs page.
After firmware update task is complete, the inventory runs automatically on the selected hosts and hosts exit automatically
from maintenance mode that is based on an option that is selected in the Schedule Updates page.
Update same firmware component type
The following are the key points to remember when updating firmware components of same type:
● If multiple components of the same type with same versions are present in the server, only one version of the component is
displayed on the Select Firmware Components page. The update will be applied to all the components and the drift details
are displayed for only one version of the component.
For example,
Table 19. Example for multiple components with same type present in server
Component Current version Available version
HDD1 V1 V3
HDD2 V1 V3
HDD3 V1 V3
In this case, the Select Firmware Components page displays the following:
Table 20. Example for multiple components of the same version present in server
Component Current version Available version
HDD1 V1 V3
● If multiple components of the same type with different versions are present in the server, a single component will
be displayed for each unique version. In this case, if you select any one component, the update will be applied to all
the components irrespective of their current firmware versions. The drift details are displayed for all the components
irrespective of their current firmware versions.
For example,
Table 21. Example for multiple components with different version present in server
Component Current version Available version
HDD1 V1 V3
HDD2 V2 V3
HDD3 V2 V3
In this case, the Select Firmware Components page displays the following:
Table 22. Example for multiple components with different version present in server
Component Current version Available version
HDD1 V1 V3
HDD2 V2 V3
Host Management 133
