6. To verify the path and authentication, click Begin Test under Test Settings.
7. Click Apply.
Managing hypervisor profiles
There are several management actions that you can perform on existing hypervisor profiles, including:
● Viewing or editing hypervisor profiles
● Deleting hypervisor profiles
Viewing or editing hypervisor profiles
1. In OpenManage Integration for VMware vCenter, on the Manage > Deployment tab, select Deployment Templates >
Hypervisor Profiles.
The hypervisor profiles are displayed.
2. Select a profile, and click the icon.
3. In the Hypervisor Profile dialog box, provide updated values.
4. To apply changes, click Save, or to cancel changes, click Cancel.
Deleting hypervisor profile
NOTE: Deleting a hypervisor profile that is part of a running deployment task can cause the task to fail.
1. In OpenManage Integration for VMware vCenter, on the Manage > Deployment tab, select Deployment Templates >
Hypervisor Profiles.
2. Select a profile, and click the
icon.
3. In the confirmation dialog box, to remove the profile, click Delete, or to cancel, click Cancel.
Creating deployment templates
A deployment template contains either a hardware profile, a hypervisor profile, or both. The deployment wizard uses this
template to provision server hardware and deploy hosts within vCenter.
1. In OpenManage Integration for VMware vCenter, on the Manage > Deployment tab, select Deployment Templates.
2. Click the icon.
3. In the Deployment Template dialog box, enter a name for the template.
4. Enter Description for the deployment template, which is optional.
5. Select a Hardware Profile or Hypervisor Profile.
6. To apply profile selections and save changes, click Save. To cancel, click Cancel.
Managing deployment templates
From the OpenManage Integration, there are several management actions you can perform on existing deployment templates,
including:
● Viewing or editing deployment templates
● Deleting deployment templates
Viewing or editing deployment templates
1. In OpenManage Integration for VMware vCenter, on the Manage > Deployment tab, select Deployment Templates.
The deployment template profiles are displayed.
2. In the Deployment Template page, select a template, click the
icon.
Deploying hypervisor
