Table 26. Virtualization events
Event name Description Severity Recommended action
occurred, which requires
additional fans
Fan redundancy is degraded One of more fans have
failed or have been removed
or a configuration change
occurred, which requires
additional fans.
Warning Remove and reinstall failed
fans or install additional fans
The fans are redundant None Info No action
The fans are not redundant One of more fans have
failed or have been removed
or a configuration change
occurred, which requires
additional fans
Info Remove and reinstall failed
fans or install additional fans
The fans are not redundant.
Insufficient resources to
maintain normal operations
One of more fans have
failed or have been removed
or a configuration change
occurred, which requires
additional fans
Critical Remove and reinstall failed
fans or install additional fans
Proactive HA events
The following table contains the Proactive HA critical, normal, and warning events; includes health update id, component type,
and description:
Table 27. Proactive HA events
Dell Inc provider event id Component type Description
DellServerFan Fan Fan redundancy event
DellServerPower Power Power redundancy event
DellServerIDSDM Storage IDSDM redundancy event
DellChassisFan Fan Chassis simulated Fan redundancy event
DellChassisPower Power Chassis simulated Power redundancy
event
Viewing alarms and events setting
Once you configure alarms and events, you can view if the vCenter alarms for hosts are enabled and which event posting level is
selected on the settings tab.
1. In OpenManage Integration for VMware vCenter, in the Manage > Settings tab, under vCenter Settings, expand Events
and Alarms.
The following details are displayed:
● vCenter alarms for Dell hosts — Displays either Enabled or Disabled.
● Event posting level
2. Configure events and alarms. See Configuring events and alarms.
To view the event posting levels, see About events and alarms.
80
Events, alarms, and health monitoring
