Users Guide

Table 14. Dell server Management portlet
Information Description
● Hypervisor—Displays the Hypervisor version
● BIOS Version—Displays the BIOS version
● Remote Access Card Version—Displays the remote
access card version
Management Consoles The management consoles are used to launch external
system management consoles, such as:
● Launching the Remote Access Console (iDRAC)—
launches the Integrated Dell Remote Access Controller
(iDRAC) web user interface.
● Launching OMSA console—launches the OMSA console
to access the OpenManage Server Administrator user
interface.
Host Actions To blink at various time intervals, set up the physical server
to blink at various time intervals. See Blink indicator light.
6. View the Dell Host Health portlet:
Table 15. Dell host health
Information Description
Dell Host Health Component health is a graphical representation of the status
of all major host server components: Server Global status,
Server, Power supply, Temperature, Voltages, Processors,
Batteries, Intrusion, Hardware log, Power management,
Power and Memory. The chassis health parameters are
applicable for models VRTX version 1.0 and later, M1000e
version 4.4 and later. For versions less than 4.3 only two
health indicators are displayed, namely Healthy and Warning
or Critical (Inverted triangle with an exclamatory mark in
orange color). The overall health indicates the health based
on the chassis with the least health parameter. The options
include:
● Healthy (green check mark)—component operating
normally
● Warning (yellow triangle with exclamation point)—
component has a noncritical error.
● Critical (red X)—component has a critical failure.
● Unknown (question mark)—status is unknown for the
component.
For example, if there are five healthy signs and one warning sign, the overall health is shown as warning.
Viewing hardware details for a single host
You can view hardware details for a single host on the Dell Hosts Information tab. For information to appear on this page, run
an inventory job. The hardware views directly report data from OMSA and iDRAC. See Running inventory jobs.
1. In OpenManage Integration for VMware vCenter, in the Navigator pane, click Hosts.
2. In the Host tab, select the specific host for which you want to view Hardware: <Component Name> details.
3. In the Monitor tab, select the Dell Host Information tab.
On the Hardware: <Component Name> subtab, view the following information for each of the components.
Table 16. Hardware information for a single host
