4 Deploying and configuring OMIVV in a dual-NIC environment
Terminology
The following table lists the terminology and acronyms that are used in this document:
Term
Description
OMIVV
OpenManage Integration for VMware vCenter
iDRAC
Integrated Dell Remote Access Controller
VM
Virtual Machine
CMC
Chassis Management Controller
OME-M
OpenManage Enterprise–Modular
NIC
Network Interface Card
LAN
Local Area Network
VLAN
Virtual Local Area Network
DNS
Domain Name System
DHCP
Dynamic Host Configuration Protocol
OOB
Out-of-Band
MAC
Address
Media Access Control Address
CIDR
Classless Inter-Domain Routing
DRS
Distributed Resource Scheduler
vSAN
Virtual Storage Area Network
vSphere
Management
Network
A network which is intended for vSphere management and has access to
vSphere components such as vCenter and ESXi.
Out-of-Band
Network
An isolated network where the iDRAC, or, CMC, or OME-M components are
connected to.
Lightning symbol in the diagram indicates that the two devices have connectivity to each other, either
within the same network or with multiple hops.
