Deploying hypervisor
OMIVV allows you to configure the following components in the supported bare-metal servers along with deploying the hypervisor and
adding it to the specified data center and cluster in a vCenter.
• Boot order setting
• RAID configuration
• BIOS configuration
• iDRAC configuration
You can create hardware profiles, hypervisor profiles on the bare-metal Dell PowerEdge servers by using VMware vCenter without using
PXE.
To provision hardware and perform deployment, ensure that the physical servers appear in the Deployment Wizard. Ensure that all
physical servers are as per the following requirements:
• Meet specific hardware support information that is available in the OpenManage Integration for VMware vCenter Compatibility
Matrix.
• Meet minimum supported versions of iDRAC firmware, Lifecycle Controller, and BIOS. See the OpenManage Integration for VMware
vCenter Compatibility Matrix for specific firmware support information.
• Configure NICs in PCI slots manually after the deployment. If you are using add-on NICs, the system must have the host LAN on
Motherboard (LOMs) enabled and connected to network. OMIVV supports deployment by using only embedded or integrated LOMs.
• Meet the storage specifications of iDSDM. To know about the storage specifications of iDSDM, see the VMware documentation.
Ensure that you enable the iDSDM from BIOS before you deploy the hypervisor with OMIVV. OMIVV allows deployment on iDSDM or
local hard drives.
• Ensure that there is a route between the vCenter and iDRAC networks if vCenter and iDRAC are connected to different networks.
• Ensure that Collect System Inventory on Reboot (CSIOR) is enabled. Also, before initiating auto/manual discovery, ensure that
retrieved data is current by completely powering off the system and then power on the system (hard reboot).
• Choose to order the Dell servers with auto discovery and handshake options preconfigured by the factory. If a server is not
preconfigured with these options, manually enter the OMIVV IP address or configure your local network to provide this information.
• Ensure that the following conditions are met before initiating hypervisor deployment if OMIVV is not used for hardware configuration:
○ Enable the virtualization technology (VT) flag in BIOS.
○ Set the system's boot order to either a bootable virtual disk or iDSDM for operating system installation.
• Verify that the BIOS setting for VT is automatically enabled even if the BIOS configuration is not part of the hardware profile, if OMIVV
is used for hardware configuration. The Express/Clone RAID configuration is required if a virtual disk is not already present on the
target system.
• Ensure that the custom ESXi images that contain all the Dell drivers are available for deployment. You can find the correct images from
support.dell.com by navigating to the Dell Drivers & Downloads page, and saving the custom images to a CIFS or NFS share
location that OMIVV can access during the deployment process. For up-to-date list of supported ESXi versions for this release, see
OpenManage Integration for VMware vCenter Compatibility Matrix. To use the correct images, see Downloading custom Dell ISO
images.
• Ensure that you have BIOS mode selected in the reference hardware profile before applying the hypervisor profile as OMIVV only
supports BIOS mode to autodeploy hypervisor on the target server. If there is no hardware profile selected, ensure that you manually
configure the boot mode as BIOS and reboot the server before applying the hypervisor profile.
NOTE: If the BOOT mode in the target system is set to UEFI, OMIVV fails to deploy the OS.
If servers are from versions earlier than Dell PowerEdge 12th generation servers, the deployment process performs the following tasks:
• Installs the OMSA package on the target system.
• Automatically configures the SNMP trap destination in OMSA to point to OMIVV.
Topics:
• Device discovery
• Provisioning
• Configuring hardware profile
• Creating hypervisor profile
12
Deploying hypervisor 89
