Chassis management
OMIVV allows you to view additional information for chassis associated with the Modular servers. In the chassis information tab, you can
view the chassis overview details for an individual chassis, information about hardware inventory, firmware and management controller,
health of the individual chassis components, and chassis warranty information. The following three tabs are displayed for each chassis and
varies for some chassis based on the models:
• Summary tab
• Monitor tab
• Manage tab
NOTE: To view all information, ensure that the chassis are associated with a chassis profile and chassis inventory is
completed successfully. See the About chassis profile for more information.
Topics:
• Viewing chassis summary details
• Viewing hardware inventory information for chassis
• Viewing additional hardware configuration for chassis
• Viewing associated host for chassis
Viewing chassis summary details
You can view the chassis summary details for an individual chassis on the Chassis Summary page.
1. In the Home page, click vCenter.
2. In the left pane, under OpenManage Integration, click Dell Chassis.
3. In the left pane, select the corresponding chassis IP.
4. Click the Summary tab.
The following information about the selected chassis is displayed:
• Name
• Model
• Firmware version
• Service tag
• CMC
NOTE: If you click the CMC link, the Chassis Management Controller page is displayed.
NOTE: If you do not run the inventory job for the chassis, you can see only service tag and CMC IP address.
5. View the health status of the devices associated with the selected chassis.
The main pane displays the overall health of a chassis. The valid health indicators are Healthy, Warning, Critical, Not Present. In
the Chassis Health grid view, the health of each component is displayed. The chassis health parameters are applicable for models
VRTX version 1.0 and later, M1000e version 4.4 and later. For versions less than 4.3, only two health indicators are displayed, such as
Healthy and Warning or Critical (Inverted triangle with an exclamatory mark in orange color).
NOTE:
The overall health indicates the health based on the chassis with the least health parameter. For example, if
there are 5 healthy signs and 1 warning sign, the overall health is shown as warning
6. View CMC Enterprise or Express with the license type and expiry date for a chassis.
The mentioned details are not applicable for M1000e chassis.
7. Click the Warranty icon and view the number of remaining days and the days used for a host.
If you have more than one warranty, the last day of the last warranty is considered to calculate the number of days left for warranty.
8. View the errors in the Active Errors table lists for a chassis, which are displayed in the Chassis Health page.
11
