Table 26. Virtualization events (continued)
Event name Description Severity Recommended action
Dell-System: Software
configuration warning
System: Software configuration
warning
Warning No action
Dell-System: Software
configuration failure
System: Software configuration
failure
Error Put the system into
maintenance mode
Dell-Storage Security warning Storage security warning Warning No action
Dell-Storage Security failure or
critical event
Storage security failure or
critical event
Error Put the system into
maintenance mode
Dell-Software change update
warning
Software change update
warning
Warning No action
Dell-Chassis Management
Controller audit warning
Chassis Management Controller
audit warning
Warning No action
Dell-Chassis Management
Controller audit failure or critical
event
Chassis Management Controller
audit failure or critical event
Error Put the system into
maintenance mode
Dell-PCI device audit warning PCI device audit warning Warning No action
Dell Power Supply audit warning Power supply audit warning Warning No action
Dell-Power Supply audit failure
or critical event
Power supply audit failure or
critical event
Error Put the system into
maintenance mode
Dell-Power usage audit warning Power usage audit warning Warning No action
Dell-Power usage audit failure or
critical event
Power usage audit failure or
critical event
Error Put the system into
maintenance mode
Dell-Security configuration
warning
Security configuration warning Warning No action
Dell-Configuration: Software
configuration warning
Configuration: Software
configuration warning
Warning No action
Dell-Configuration: Software
configuration failure
Configuration: Software
configuration failure
Error Put the system into
maintenance mode
Dell-Virtual Disk Partition failure Virtual disk partition failure Error Put the system into
maintenance mode
Dell-Virtual Disk Partition
warning
Virtual disk partition warning Warning No action
iDRAC events
NOTE: For all Proactive HA enabled hosts that are part of a cluster, the following virtualization events are mapped to
the Proactive HA events; except events, "The fans are not redundant" and "The power supplies are not redundant" are
not mapped.
The fans are redundant None Info No action
Fan redundancy is lost One of more fans have failed or
have been removed or a
configuration change occurred,
which requires additional fans
Critical Remove and reinstall failed fans
or install additional fans
Fan redundancy is degraded One of more fans have failed or
have been removed or a
configuration change occurred,
which requires additional fans.
Warning Remove and reinstall failed fans
or install additional fans
The fans are not redundant One of more fans have failed or
have been removed or a
Info Remove and reinstall failed fans
or install additional fans
76 Events, alarms, and health monitoring
