NOTE: To display the full list of details, select a specific host from the data grid.
Table 20. Overview of data centers and clusters
Information Description
Datacenter/Cluster Information Displays the following:
• Datacenter/cluster name
• Number of Dell’s managed hosts
• Total energy consumption
Hardware Resources Displays the following:
• Total Processors
• Total Memory
• Virtual Disk Capacity
Warranty Summary Displays the warranty status for the selected host. The status
options include:
• Expired warranty
• Active warranty
• Unknown warranty
Host Displays the host name
Service Tag Displays the host service tag
Model Displays the Dell PowerEdge model
Asset Tag Displays the asset tag, if configured
Chassis Service Tag Displays the chassis service tag, if applicable
OS Version Displays the ESXi OS version
Location Blades only: Displays the slot location. For other, displays “Not
Applicable”
iDRAC IP Displays the iDRAC IP address
Service Console IP Displays the service console IP
CMC URL Displays the CMC URL, which is the Chassis URL for Blade
servers, or else, it displays, “Not Applicable”
CPUs Displays the number of CPUs
Memory Displays the host memory
Power State Displays, if the host has power
Last Inventory Displays the day, date, and time of the last inventory job
Connection Profile Displays the name of the connection profile
Remote Access Card Version Displays the remote access card version
BIOS Firmware Version Displays the BIOS firmware version
Viewing hardware details for data centers and clusters
You can view hardware details for a single host on the Dell Datacenter/Cluster Information tab. For information to appear on this
page, run an inventory job. The data center and cluster pages enable you to export information to a CSV file and offer filter or search
functionality on the data grid. The data you view might vary depending on which view you are accessing the data. The hardware views
directly report data from OMSA and iDRAC. See Running inventory jobs.
1. In OpenManage Integration for VMware vCenter, in the Navigator pane, click vCenter Inventory Lists.
