Table 44. Managed nodes (continued)
Port number Protocols Port type Max.
Encryption
Level
Direction Usage Configurable
69 TFTP UDP 128–bit In/Out Trivial File
Transfer
No
111 NFS UDP/TCP 128–bit In SUN Remote
Procedure Call
(Portmap)
No
68 BOOTP UDP None Out Bootstrap
Protocol Client
No
What are minimum requirements for successful
installation and operation of virtual appliance?
The following settings outline the minimum appliance requirements:
• Google chrome, version 28 and later
• Microsoft Internet Explorer, version 9 and 10
• Mozilla Firefox, version 22 and later
• Reserved memory—2 GB
NOTE: For optimal performance, Dell recommends 3 GB.
• Disk—44 GB
• CPU—2 virtual CPUs
Why is password not changed for user used for bare-metal
discovery after successfully applying hardware profile that
has same user with new changed credentials in iDRAC user
list?
The password of the user used from discovery is not changed to the new credential if only hardware profile template is selected for
deployment. This is done intentionally so that the plug-in is able to communicate with the iDRAC for future use in deployment needs.
Why am I unable to view new iDRAC version details listed
on vCenter hosts and clusters page?
Resolution: After successful completion of a firmware update task in the vSphere web client, refresh the Firmware Update page and
verify the firmware versions. If the page displays the old versions, go to the Host Compliance page in OpenManage Integration for
VMware vCenter, and check the CSIOR status of that host. If CSIOR is not enabled, enable CSIOR and reboot host. If CSIOR is already
enabled, log in to the iDRAC console, reset iDRAC, wait for few minutes, and then refresh the Firmware Update page.
How can I test event settings by using OMSA to simulate
temperature hardware Fault?
To ensure that events are functioning correctly, perform the following steps:
1. In the OMSA user interface, navigate to Alert Management > Platform Events.
2. Select the Enable Platform Event Filter Alerts check box.
3. Scroll down to the bottom, and click Apply Changes.
4. To ensure that a specific event is enabled, such as temperature warning, from the tree on the left, select Main System Chassis.
