Troubleshooting
Use this section to find answers to troubleshooting questions. This section includes:
• Frequently asked questions (FAQ)
• Bare-metal deployment issues on page 128
Topics:
• Frequently Asked Questions (FAQ)
• Bare-metal deployment issues
Frequently Asked Questions (FAQ)
This section contains some common questions and solutions.
Why Export All button fails to export to .CSV file in Google
chrome?
After registering a vCenter server, if you add a host and create a connection profile, and then view the inventory details of the host, the
Export All button returns a failure. The Export All button does not export the information to a .CSV file.
NOTE:
In all versions of the Google chrome browser, the Export All button does not export the information to a .CSV file in
Incognito mode.
Resolution: To export information to a .CSV file by using the Export All button in the Google chrome, disable the Incognito mode in
chrome browser.
Version affected: 4.0
iDRAC license type and description are displayed
incorrectly for non-compliant vSphere hosts
If a host is noncomplaint when CSIOR is disabled or has not been run, iDRAC license information is displayed incorrectly although valid
iDRAC license is available. Hence, you can view the host in vSphere hosts list, but when you click the host for details, the information in
iDRAC License Type is displayed as empty and iDRAC License Description is displayed as ”Your license needs to be upgraded".
Resolution: To fix this issue, enable CSIOR on a reference server.
Version affected: 4.0
Dell icon is not displayed after unregistering vCenter from
earlier OMIVV version and then registering same vCenter
with later OMIVV version
If you unregister an earlier OMIVV version with vCenter server, and then register a later OMIVV version with the same vCenter server,
there is an entry in the vsphere-client-serenity folder, which is old data from the earlier OMIVV version. Hence, the Dell icon is not
displayed after registering the later OMIVV version as old data specific to the earlier OMIVV version exists in the vsphere-client-serenity
folder of the vCenter appliance.
Resolution: Perform the following steps:
