Users Guide

MapQuest Bing
• Roads map — A simple, fast loading map with minimal
details.
• Satellite map — Provides detailed satellite views of the
world.
NOTE: The MapQuest and the Bing map providers require an internet connection at all times to render the map. If the
system connects to the internet through a proxy server, the proxy settings configured in your web browser is used by
the MapQuest and Bing providers.
Related links
Using Map View
Configuring Map Settings
NOTE: Only OpenManage Essentials Administrators and Power Users are permitted to configure Map Settings.
The Map Settings dialog box allows you to enable or disable the Internet connection status notification and to provide a valid Bing
key required by the Bing map provider or MapQuest key required by the MapQuest map provider.
To configure the map settings:
1. Perform one of the following:
• Click Home → Map View.
• Click Manage → Devices → Map View.
2. On the Map View:
• Right-click anywhere on the map, and then click Settings.
• Move the mouse pointer over the Actions menu, and click Settings.
The Map Settings dialog box is displayed.
3. Select Update map view on any device or device group selection if you want the map to display only the pin or pins that
correspond to the device or device group selected in the device tree.
4. Select Show internet connection warning when unable to connect to the internet if you want to display a warning on the
map if an Internet connection is not available.
5. Select one of the following map providers:
• MapQuest
• Bing
6. In the Key field, type the appropriate map provider key.
7. Click Apply.
Related links
Using Map View
General Navigation and Zooming
To move the map, click and drag the map in the desired direction or use the navigation arrows in the Navigation toolbar.
You can zoom in or zoom out of the map using any of the following methods:
• Double-click a pin to zoom in to street level around that pin. You can also zoom in to street level by:
– Right-clicking a pin, and then clicking Zoom to Street Level
– Moving the mouse pointer over the Actions menu, and then clicking Zoom to Street Level
• If a pin is displayed at street level, double-click the pin to zoom out to the world-level view
• Double-click a location on the map to zoom-in one level at that location
• Move the mouse wheel up or down to quickly zoom out or in on the map
