9. If you want to configure the SMTP email server, click Email Settings.
The Email Settings page is displayed. For more information about Email Settings, see Email Settings.
10. Click Apply.
OpenManage Essentials sends warranty notification emails based on your configuration. The warranty notification email provides a
list of devices and appropriate links that you can click to renew the warranty of the devices.
Related links
Warranty Notification Settings
Configuring Warranty Scoreboard Notifications
You can configure OpenManage Essentials to display a warranty scoreboard notification icon in the heading banner. For information
about the options you can configure, see Warranty Notification Settings.
To configure Warranty Scoreboard Notifications:
1. Click Settings → Warranty Notification Settings.
The Warranty Notification Settings page is displayed.
2. Under Warranty Scoreboard Notifications, select Enable Warranty Scoreboard Notifications.
3. To set the criteria for the devices to be included in the warranty notification scoreboard, in the All Devices with x Days or less
of warranty
field, select the number of days.
4. To include devices with expired warranty or no warranty information in the warranty notifications scoreboard, select Include
Devices with Expired Warranties
.
5. Click Apply.
If any device meets the set criteria, the OpenManage Essentials heading banner displays the warranty scoreboard notification icon
including the number of devices.
Related links
Using the Warranty Scoreboard Notification Icon
Device Warranty Report
Warranty Notification Settings
Configuring Warranty Pop-Up Notifications
You can configure OpenManage Essentials to display warranty pop-up notifications based on the warranty status of the devices.
For information about the options you can configure, see Warranty Notification Settings.
To configure warranty pop-up notifications:
1. Click Settings → Warranty Notification Settings.
The Warranty Notification Settings page is displayed.
2. In Warranty Popup Notification Settings:
• Select the Enable Warranty Popup Notifications option to enable warranty pop-up notifications.
• Clear the Enable Warranty Popup Notifications option to disable warranty pop-up notifications.
3. Click Apply.
Using Map View
NOTE: For information about using the features available in Map View, see Map View (Home) Portal.
NOTE: The map displayed in Map View should be considered
as is
from the map service provider. OpenManage
Essentials does not have any control over the accuracy of the map or address information.
NOTE: An Internet connection is required to perform some of the map functions such as zoom, address search, and so
on. If you are not connected to the Internet, the following message is displayed on the map: Warning — Unable to
connect to the Internet!
.
91
