Related links
Creating a Discovery and Inventory Task
Viewing Configured Discovery and Inventory Ranges
Excluding Ranges
Scheduling Discovery
Scheduling Inventory
Configuring Status Polling Frequency
Discovery and Inventory Portal
Task Status
The grid provides a list of currently executing and previously run tasks and their status. The Task Status grid on this page shows
the status of just discovery, inventory, and tasks. However, the main portal shows all types of task statuses.
Related links
Creating a Discovery and Inventory Task
Viewing Configured Discovery and Inventory Ranges
Excluding Ranges
Scheduling Discovery
Scheduling Inventory
Configuring Status Polling Frequency
Discovery and Inventory Portal
Viewing Device Summary
1. In OpenManage Essentials, click Manage → Discovery and Inventory → Discovery Portal → Discovery Portal.
2. In Discovered vs. Inventoried Devices graphical report, click the bar representing the discovered or inventoried device to open
the Device Summary page that displays the selected graph details.
3. (Optional) Click the funnel icon to filter the summary information.
The filter options are displayed. See Viewing Device Summary Filter Options.
4. (Optional) Click Filter to view the filtered summary information.
5. (Optional) Click Clear Filter to remove the filtered summary information.
6. Right-click a device summary and select from the available options. See Device Status.
Viewing Device Summary Filter Options
Table 20. Viewing Device Summary Filter Options
Field Description
Select All Select to filter per line item.
Select options, devices, or Dell servers. Select to filter based on options, devices, or Dell servers.
Filter options Create filter with these options:
• Is equal to— Select to create the same as logic.
• Is not equal to — Select to create the different from logic.
• Is Less than— Select to find a value that is less than the
value you provide.
• Is less than or equal to— Select to find a value that is less
than or equal to the value you provide.
• Is greater than or equal to— Select to find a value that is
greater than or equal to the value you provide.
71
