• Warranty scoreboard notification icon including the number of devices with x days or less of warranty. You can click the
icon or number to view the Device Warranty Report that lists the device with certain days or less of warranty. The warranty
scoreboard notification icon is displayed only if you have selected Enable Warranty Scoreboard Notifications in Settings →
Warranty Notification Settings.
In addition to the icons, the banner also contains links to the following:
• Dell TechCenter — Click to view the information on various technologies, best practices, knowledge sharing, and information
on Dell products.
• Support — Click to open dell.com/support.
• Help — Click to open the online help.
• About — Click to view general OpenManage Essentials product information.
•
User name
— Displays the user name of the currently logged in user. Move the mouse pointer over the user name to display
the following options:
– User Info — Click to view the OpenManage Essentials roles associated with the current user.
– Sign in as Different User — Click to log in to OpenManage Essentials as a different user.
NOTE: The Sign in as Different User option is not supported on Google Chrome.
NOTE: The banner is available in all the pages.
Related links
Viewing the User Information
Logging On As a Different User
Using the Update Available Notification Icon
Using the Warranty Scoreboard Notification Icon
Customizing Portals
You can change the layout of the portal page to do the following:
• Display additional available reports.
NOTE: This option is only available in the Home portal.
• Hide graphs and reports.
• Rearrange or resize graphs and reports by dragging and dropping.
If a pop-up window on any screen is bigger than the screen and if scrolling is not possible, set the zoom value of the browser to
75% or less.
From the various reports that are available, you can select specific reports and set them to display on the Dashboard. You can click
these reports to get more details. For the list of available reports, see Home Portal Reports.
For more information on the:
• Home portal, see OpenManage Essentials Home Portal Reference.
• Device portal, see Devices Reference.
• Discovery and inventory portal, see Discovery And Inventory Reference.
• Reports portal, see Reports Reference.
.
Displaying Additional Available Reports and Graphs
Charts have drill-down feature. To view additional reports and graphs, click the
39
