• PS> Add-DiscoveryRange –Profile .\Samples\DiscoveryProfile.xml -RangeListCSV .\Samples
\RangeList.csv
Removing a Discovery Range
Description: The Remove-DiscoveryRange command allows you to remove a discovery range. Enter the ranges either using an
xml file or by specifying the range. For more information about the
RangeList.xml file, see Specifying IPs, Ranges, or Host Names
Using XML or CSV Files.
Commands:
•
PS> Remove-DiscoveryRange -Range <range>
• PS> Remove-DiscoveryRange -RangeList <rangelist.xml>
Examples:
• PS> Remove-DiscoveryRange-Range 10.35.0.1, 10.120.1.2
• PS> Remove-DiscoveryRange -RangeList .\Samples\RangeList.xml
Creating a Discovery Range Group
Description: The Add-DiscoveryRangeGroup command allows you to create a discovery range group. A discovery range group
can either contain a range of IPs, individual IPs, or host names under it. This enables you to modify protocols settings for the group
and all the ranges it contains. You can maintain different sets of protocols for different types of devices in your network. With
ranges not in a group, you have to edit each range individually to change the protocols which are active, the time out or retry values,
or credentials used with each protocol. Each discovery range group can only have one corresponding subnet. The subnet for a
group is read from the DiscoveryProfile.xml file and not from the Rangelist.xml or RangeList.csv file. If required, create multiple
groups for each subnet. For more information about DiscoveryProfile.xml, Rangelist.xml, and RangeList.csv files, see Creating a
Discovery Profile Input File and Specifying IPs, Ranges, or Host names Using XML or CSV Files.
Command:
• PS> Add-DiscoveryRangeGroup –Profile <DiscoveryProfile.xml> -GroupName <group name> -
RangeList <Rangelist.xml>
• PS> Add-DiscoveryRangeGroup –Profile <DiscoveryProfile.xml> -GroupName <group name> -
RangeListCSV <Rangelist.csv>
Examples:
• PS> Add-DiscoveryRangeGroup –Profile .\Samples\DiscoveryProfile.xml -GroupName Group1 -
RangeList .\Samples\rangelist.xml
• PS> Add-DiscoveryRangeGroup –Profile .\Samples\DiscoveryProfile.xml -GroupName Group1 -
RangeListCSV .\Samples\rangelist.csv
Removing a Discovery Range Group
Description: The Remove-DiscoveryRangeGroup command allows to you to remove a discovery range group.
Command:
PS>Remove-DiscoveryRangeGroup -GroupName <groupname>
Example:
PS>Remove-DiscoveryRangeGroup -GroupName Group1
Editing a Discovery Range
Description: The Set-ModifyDiscoveryRange command allows to edit existing discovery ranges. This command targets the
existing specified discovery range(s) and replaces the protocol information with the information specified in the DiscoveryProfile.xml
374
