Action Description
Reclaim Identities Reclaim the virtual I/O identities of the server.
Remove from Pool Remove a server from the compute pool.
Replace Server Replace a server with another server from within the same
compute pool.
Virtual I/O Pools
Virtual I/O Pool
Table 279. Virtual I/O Pool
Action Description
Create Virtual I/O Pool Create a virtual I/O pool.
Edit Edit the virtual I/O pool.
View View the virtual I/O pool wizard.
Rename Rename the virtual I/O pool.
Delete Delete the virtual I/O pool.
Devices with Identities
Table 280. Device with Identities
Action Description
View Identities View the deployed and assigned virtual I/O identities of a
device.
Reclaim the Assigned Identities Reclaim the assigned virtual I/O identities of a device.
Reclaim the Deployed Identities Reclaim the deployed virtual I/O identities of a device.
Export Export the details in an HTML, CSV, Text, or XML format.
Compliance by Template
Table 281. Compliance by Template
Action Description
Associate Devices Deploy the selected device configuration template.
Edit Displays the attributes of the selected device configuration
template in the right pane for editing.
Clone Clone the selected device configuration template.
Rename Rename the selected device configuration template.
Delete Delete the selected device configuration template.
Export Template Export the selected device configuration template.
.
368
