3
Getting Started With OpenManage Essentials
Launching OpenManage Essentials
To launch OpenManage Essentials, do one of the following:
NOTE: Before you launch OpenManage Essentials, ensure that Javascript is enabled on your web browser.
• From the management station desktop, click the Essentials icon.
• From the management station desktop, click Start → All Programs → Dell OpenManage Applications → Essentials →
Essentials.
• From a local or remote system, launch a supported browser. In the address field, type any of the following:
– https://< Fully Qualified Domain Name (FQDN) >:
– https://<IP address, host name, or Fully Qualified Domain Name (FQDN) >:<Port Number>/web/default.aspx
– https://<IP address>:<Port Number>/
NOTE: FQDN is required to show a valid certificate. The certificate shows an error if an IP address or local host is used.
The console launch port number (default port number 2607) is required to launch OpenManage Essentials from a browser on a
remote system. While installing OpenManage Essentials, if you changed the port using the Custom Install option, use the selected
console launch port in the preceding URL.
The First Time Setup page is displayed.
NOTE: You can log on to OpenManage Essentials as a different user at any time by using the Sign in as Different User
option. For more information, see Logging On As a Different User.
Related links
Using the OpenManage Essentials Home Portal
Configuring OpenManage Essentials
If you are logging on to OpenManage Essentials for the first time, the First Time Setup tutorial is displayed. The tutorial provides
step-by-step instructions for setting up an environment of servers and devices to communicate with OpenManage Essentials. The
steps include:
• Configuring the SNMP protocol on each target server.
• Installing SNMP tools (for Windows Server 2012 or later).
• Installing Dell OpenManage Server Administrator on each target server.
• Enabling network discovery (for Windows Server 2008-based servers) on each target server.
• Discovering devices on your network.
After you have completed the First Time Setup wizard, the Discovery Wizard Configuration window is displayed. See Discovery
Wizard Configuration.
The date and time displayed in the console is in a format that is selected in the browser settings and used in the region. When a time
zone change or daylight savings change occurs, the time is updated accordingly in the console. Changing time zones or daylight
savings, changes the time in the console, but does not change the time in the database.
36
