Answer: In some cases, when attribute values are deployed to multiple partitions, the FQDD values shown in the results tab may be
incorrect (specifically, the same FQDD may be repeated for different partitions). However, correct values are stored in the
database. You can view the device configuration inventory to see the actual values.
Question: I replaced a server (source) with another server (target) from a compute pool. Will the existing alerts and tasks be
associated to the target server?
Answer: The following are the expected behaviors after replacing the server (where source refers to the source operating system):
• Alerts and tasks that were created before replacing the server are associated only with source server.
• Alerts and tasks that are created after the replacing the server are associated only with the target server.
Question: When OpenManage Essentials performs deployment in QLogic CNA cards, sometimes the value of second octet for
virtual WWPN and WWNN gets set to 08 and 07, instead of 01 and 00. How do I resolve this issue?
Answer: Perform the following steps:
1. Clear all NIC partitions.
2. Reboot the server.
3. Partition the NIC again.
4. Deploy the server again with virtual I/O attributes.
Question: I deployed a configuration template on a server. What must I do if I want to edit some attributes of the same
configuration template and then deploy it on another server?
Answer: It is recommended that you clone the configuration template, edit the attributes, and then deploy the cloned template on
another server.
Logs
Question: How do I enable logging in OpenManage Essentials?
Answer: To enable logging:
1. Go to C:\Program Files\Dell\SysMgt\Essentials\configuration or the path where OpenManage Essentials is installed.
2. Open the dconfig.ini file using notepad.
3. In the [Logging] section, modify the following:
• Set LOG_ENABLED=true to enable logging.
• Set LOG_TO_FILE=true to write logs to a file.
• Type a path for LOG_FILE_PREFIX. For example, LOG_FILE_PREFIX=C:\windows\temp.
• If required, change the suffix of the file for LOG_FILE_SUFFIX=ome_log.txt.
• Set the log level for LOG_LEVEL_MIN. For example, LOG_LEVEL_MIN=debug.
NOTE: Setting the minimum log level (LOG_LEVEL_MIN) to debug or trace reduces the performance of
OpenManage Essentials.
• Set the log level for LOG_LEVEL_MAX. For example, LOG_LEVEL_MAX=output.
NOTE: The maximum log level (LOG_LEVEL_MAX) must always be set to output.
NOTE: For more information about log severity levels, see the “Log Levels” section.
4. Close the file and restart all DSM services in the Services Microsoft Management Console.
Log Levels
Setting the log levels determines the range of message severity type you want to log. The following table describes the log message
severity levels that you can assign to LOG_LEVEL_MIN and LOG_LEVEL_MAX.
342
