Field Description
• Run now — Select this option to run the task immediately.
• Set schedule — Select this option to set a date and time
for the task to run.
• Run Once — Select this option to run the task on the
planned schedule only once.
• Periodic — Select this option to run the task frequently at
specified intervals.
– Hourly — Select this option to run the task once
every hour.
– Daily — To run the task once every day.
– Weekly — To run the task once every week.
– Monthly — To run the task once every month.
Range of Recurrence:
• Start — To specify the date and time at which the task
should begin.
• No End Date — To continuously run this task based on the
selected frequency. For example, if you selected Hourly,
then this task continuously runs every hour from the start
time.
• End By — To stop the task at the specified date and time.
Enter the credentials with appropriate privileges to run this
task on this system
User Name — Provide OpenManage Essentials user credentials
in the format domain\user name or local host\user name.
Password — Provide the password.
Related links
Command Line Task
Managing Command Line Task
Using the Sample - Server XML Configuration Command Line Task
IPMI Command
Table 234. IPMI Command
Field Description
Command Provide the IPMI command you want to run on selected targets.
Ping Device
This option performs a ping test to verify if a device is reachable
before it runs a task against it. This option can be used when
using $IP or $RAC_IP and it decreases the time it takes to run
the task(s) as it skips unreachable devices.
Output to file Select to enable output to a log file. This option captures
standard output from the running application and writes it to the
log file. If you select this option, enter the path name and file
name of the log file. This option is disabled by default.
Append Select to append output from the completed command to the
specified file. If the file does not exist, it is created.
Include errors Select to write all OpenManage Essentials-detected errors to
the log file. For example, if no response is received to a ping
313
