Dell Lifecycle Controller 2 version 1.2 or later
RACADM version 7.2 or later
Firmware version 1.30.30 or later
Express or Enterprise license
iDRAC7
The Sample - Server XML Configuration command line task allows you to apply a specific server configuration to multiple managed
nodes. Using Dell Lifecycle Controller 2 version 1.2 or later, a server configuration summary can be exported from an iDRAC in XML
format through the “Export Server Configuration” operation.
NOTE: For information on exporting the server configuration summary using Lifecycle Controller 2, see the
Configuration XML Workflows
white paper at DellTechCenter.com/LC.
The server configuration summary XML file can be applied to another iDRAC using the Sample - Server XML Configuration
command line task.
NOTE: To apply the server configuration summary from one iDRAC to another iDRAC, both the iDRACs must be of the
same generation, same license state, and so on. For more information on the requirements, see the
Lifecycle Controller
(LC) XML Schema Guide
,
Server Configuration XML File
, and
Configuration XML Workflows
white papers at
DellTechCenter.com/LC.
To use the Sample - Server XML Configuration command line task:
1. In the OpenManage Essentials Remote Tasks portal, right-click the Sample - Server XML Configuration, and click Clone.
The Input information for the newly cloned task dialog box is displayed.
2. Provide the Cloned Task Name and click OK.
3. Right-click the created cloned task and click Edit.
The Create a Command Line Task dialog box is displayed.
4. Edit the Command field, and provide the location of the server configuration summary xml file in the OpenManage Essentials
management station. For example, set –f c:\user1\server1.xml-t xml, where c:\user1\server1.xml is the
location of the server configuration summary xml file.
5. In the Targets tab, select the appropriate targets for applying the server configuration.
6. In the Schedule and Credentials tab, select to run or schedule the task, and provide the required credentials.
7. Click Finish.
Device Capability Matrix
The following device capability matrix provides information about the type of remote tasks supported on devices that are displayed
in the Task Target tab.
Table 224. Type Of Remote Tasks Supported On Devices That Are Displayed In The Task Target Tab
Remote Task Type
All Servers (except
ESXi) With Server
Administrator and
Discovered Using
SNMP/WMI
Windows-based
Servers without
Server
Administrator and
discovered using
WMI
Linux-based
Servers without
Server
Administrator and
discovered using
SSH
DRAC/iDRAC
discovered using
IPMI
DRAC/iDRAC
discovered using
SNMP/WS-Man
DRAC/iDRAC is not discovered Server operating system is not
discovered
Reboot/power
cycle operation
Supported Supported Not supported Not supported Not supported
Power off operation Supported Supported Not supported Not supported Not supported
Power on operation Not supported Not supported Not supported Supported Not supported
