• Type the host name and database instance name in the Database Server field.
9. Click Windows authentication or SQL Server authentication.
NOTE: For Windows authentication, if you are using a non-domain Windows account, the credentials must exist on
both the domain controller and the remote system, and should also be identical. The Windows user account must
have the privileges required to create databases in SQL Server.
10. Type the user name and password in the appropriate fields and click Next.
The Ready to Install the Program window is displayed.
11. Click Install.
After the installation of OpenManage Essentials is completed, add the logged in administrator to the OMEAdministrators user group.
See Adding Users to the OpenManage Essentials Groups.
NOTE: After the OpenManage Essentials database is set up on the remote system, if the database is either moved or
altered, open OpenManage Essentials to re-target using the new database connection settings.
Installing OpenManage Essentials on a Domain Controller With a Local Database
Before you begin installing OpenManage Essentials on a domain controller, ensure that you are logged in to the domain controller
with administrator rights.
To install OpenManage Essentials on a domain controller with a local database:
1. Extract the OpenManage Essentials installation package.
2. Double-click the Autorun.exe file available within the folder where you extracted the installation package.
The Dell OpenManage Install window is displayed.
3. Select Dell OpenManage Essentials and click Install.
The OpenManage Essentials Prerequisites window is displayed.
NOTE: If SQL Server is not already installed on the domain controller, the Prerequisites window displays a warning
message with a link that allows you to install SQL Express on the domain controller (local) with an OpenManage
Essentials-specific SQLEXPRESSOME database instance.
4. In the Prerequisites window, click the link to install SQL Express on the domain controller.
5. Create a domain service account required to run SQL Server on the domain controller. See Creating a Domain Service Account.
6. Configure the SQLEXPRESSOME instance to run using the domain service account. See Configuring the Database Instance.
7. Click Install Essentials on the Prerequisites window, and follow the instructions on the screen to complete the installation of
OpenManage Essentials.
After the installation of OpenManage Essentials is completed, add the logged in administrator to the OMEAdministrators user group.
See
Adding Users to the OpenManage Essentials User Groups.
Creating a Domain Service Account
A domain service account is required to run SQL Server on the domain controller.
To create a domain service account:
1. Click Start → Administrative Tools.
2. Select Active Directory Users and Computers.
3. On the left pane, right-click Managed Service Account → New → User.
The New Object – User window is displayed.
4. Type the first name and user logon name in the appropriate fields, and click Next.
5. Type a password and reconfirm the password in the appropriate fields, and click Finish.
30
