Working With Sample Remote Tasks Use Cases
Sample remote tasks are available for Server Power Options, Deploy Server Administrator, and Command Line. Sample remote tasks
use cases are disabled by default. To enable a sample use case:
1. Right-click the use case and select Clone.
2. Enter the Cloned Task Name and click Ok.
3. Right-click the cloned task and select Edit.
4. Enter the required information and assign targets to the tasks. For information about the options, see Remote Tasks
Reference.
Related links
Remote Tasks
Remote Tasks — Reference
Remote Tasks Home
Command Line Task
All Tasks
Device Capability Matrix
Use Cases in Remote Tasks
Server Power Options
Sample-Power On Device—Enable this use case to turn on the server. The system must have RAC/DRAC configured.
Deploy Server Administrator
Sample-OMSA Upgrade Windows—Enable this use case to upgrade OpenManage Server Administrator on a Windows-based
system.
Command Line
• Sample - Windows OMSA Uninstall — Enable this use case to uninstall OMSA on a system running the Windows Server
operating system.
• Sample - Linux OMSA Uninstall — Enable this use case to uninstall OMSA on a system running the Linux operating system.
• Sample - Server XML Configuration — Enable this use case to apply a specific server configuration to multiple managed
nodes. For more information, see Using the Sample - Server XML Configuration Command Line Task.
• Sample-Generic Command Remote — Enable this use case to use tokens to receive the IP address or name of inventories
systems.
NOTE: To use this command, you must enter the local system credentials.
• Sample - Generic Command Local — Enable this use case to run a command or script on system with OpenManage Essentials.
NOTE: To use this command, you must enter the local system credentials.
• Sample - IPMI Command — Enable this use case to receive information about the power status of a server.
• Sample - Remote Command — Enable this use case to view the system summary through Server Administrator.
• Sample - RACADM - Clear SEL Log — Enable this use case to clear the SEL log of RAC.
• Sample - RACADM-Reset — Enable this use case to reset the RAC.
Firmware and Driver Inventory Task
Scheduled S/W Inventory Task — Enable this use case to collect firmware and driver inventory from a server.
Using the Sample - Server XML Configuration Command Line Task
The following are the prerequisites for using the Sample - Server XML Configuration command line task:
299
