a. Select Windows or Linux.
b. If applicable, select 64-bit System.
NOTE: By default, target devices that have OMSA installed are not displayed on the Task Targets tab.
c. Select Show OMSA based targets to also view target devices that have OMSA installed in the Task Target tab.
d. If you selected Show OMSA based targets, perform one of the following in the Future Software Inventory Data
Collected by
section:
NOTE: The Future Software Inventory Data Collected by options only determine the method OpenManage
Essentials utilizes to gather firmware and driver inventory information from target devices after an in-band
system update. If the F/W and Driver task based inventory option is selected, scheduled discovery and inventory
cycles will still gather the OMSA-based inventory from target devices, except the information in the Software
Inventory table.
• OMSA based inventory — Select to revert to gathering firmware and driver inventory information through OMSA on
target devices that have OMSA installed.
NOTE: To revert to gathering firmware and driver inventory information through OMSA, you must either run
the firmware and driver inventory task or delete and rediscover the device.
• F/W and Driver task based inventory — Select to gather firmware and driver inventory information through the
inventory collector component, even though OMSA may be installed on the device.
4. On Task Target, do one of the following:
• Select a query from the drop-down list or click New to create a new query.
• Select servers on which you want to run this task and click Next.
5. On Schedule and Credentials, set the schedule parameters, provide user credentials to enable the task.
6. Click Finish.
The status of the inventory collection is displayed in the Task Execution History of the Remote Tasks portal.
Related links
Remote Tasks
Remote Tasks — Reference
Remote Tasks Home
Command Line Task
All Tasks
Device Capability Matrix
Firmware and Driver Inventory Collection Task
Updating the inventory collector component
The Create F/W & Driver Inventory Task utilizes the inventory collector component to collect software inventory information from
Dell servers. Occasionally, a newer version of the inventory collector component may be available. You can verify if OpenManage
Essentials has the latest version of the inventory collector component through the Dell Solutions portal. If a newer version of the
inventory collector component is available, the Update link is displayed on the Dell Solutions portal.
To update the inventory collector component:
1. Click Dell Solutions.
The Dell Solutions portal is displayed.
2. Click the Update link displayed in the Inventory collector component row.
3. At the confirmation prompt, click Yes.
The inventory collector component is downloaded in the background. You can view the status of the update in the Task Status grid
on the Home portal.
298
