The Login - New window is displayed.
4. In the General page:
a. Type a name in the Login name field.
b. Select Windows authentication or SQL Server authentication based on your preference.
c. Type the password and reconfirm the password in the appropriate fields.
d. Optional: If you want to enforce password policy options for complexity, select Enforce Policy Password.
e. From the Default database list, select OMEssentials.
f. From the Default language list, select a default language for the login.
5. In the Server Roles page, select public.
6. In the User Mappings page:
a. Under Users mapped to this login, select OMEssentials.
b. Under Database role membership for: OMEssentials, select db_owner and public.
7. Click OK.
The new user that you created is displayed under Security → Logins in Object Explorer.
Connecting to the OpenManage Essentials Database
To connect to the OpenManage Essentials database:
1. On the system where OpenManage Essentials is installed, open the command prompt, and run the following command:
sqlcmd -E -S ".\SQLEXPRESSOME" -Q "ALTER LOGIN [OMEService] WITH
PASSWORD='DummyPassword'"
NOTE: Verify that the OpenManage Essentials database instance that was created during the typical installation is
SQLEXPRESSOME.
NOTE: Copying and pasting the command may result in incorrect characters. Therefore, it is recommended that you
type the complete command.
2. Open OpenManage Essentials.
The database login error window is displayed.
3. Click OK on the database login error window.
The Database Connection Error window is displayed.
4. In the Database Connection Error window:
a. In the Server Name field, type the name of the system where you restored the OpenManage Essentials database.
b. From the Authentication list, select the authentication method for the database.
c. Type the user name and password of the new user you created in the appropriate fields.
d. Type the name of the database that you have already created in SQL Server.
e. Click Connect.
5. Close and reopen OpenManage Essentials.
6. Restart the Internet Information Services (IIS).
7. Restart the OpenManage Essentials services or restart the server.
After the database retargeting is completed successfully, if required, you can delete the OpenManage Essentials database from the
system on which OpenManage Essentials is installed.
Installing OpenManage Essentials on a Domain Controller
When installing OpenManage Essentials on a domain controller, it is recommended that you install OpenManage Essentials with a
remote database. There are specific restrictions when running SQL Server on a domain controller, and considering the resources
demands of a domain controller, SQL Server performance may be degraded which will affect the performance of OpenManage
Essentials. For more information on the restrictions when running SQL Server on a domain controller, see the Microsoft Knowledge
Base article ID 2032911 at support.microsoft.com.
28
