Viewing Comparison Results
This section provides information required to view the results of the comparison of devices to a source catalog.
Viewing Compliant Servers
To view compliant servers:
1. Click Manage → System Update.
2. In System Update, select the Compliant Systems tab.
Viewing Non-Compliant Systems
To view non-compliant systems:
1. Click Manage → System Update.
2. In System Update, select the Non-Compliant Systems tab.
Systems with drivers and firmware versions that are different from the catalog are displayed.
Viewing Non-Inventoried Systems
To view non-inventoried systems:
1. Click Manage → System Update.
2. In System Update, select the Non-Inventoried Systems tab.
Systems that are not inventoried are displayed.
NOTE: CMC firmware updates (CMC active controller only) are also displayed in these results.
NOTE: To inventory the non-inventoried servers, you can select the non-inventoried servers and click Inventory.
The method of inventory collection may vary based on the following criteria:
• If the server is discovered through SNMP and has OMSA installed, the default discovery and inventory is initiated.
• If the server is discovered through WMI/SSH and does not have OMSA installed, the Create F/W & Driver
Inventory Task window is displayed.
Viewing Systems With Issues and Resolutions
To view systems with issues and resolutions:
1. Click Manage → System Update.
2. In System Update, select the Issues and Resolutions For Updates tab.
Systems with issues and the resolutions are displayed. For more information, see Issues and Resolutions Use Case Scenarios.
System Update Use Case Scenarios
The following table provides use case scenarios about how system updates occur based on different protocols and the update
modes.
NOTE: If the preferred system update method selected in Advanced Settings is In-Band (Operating System) and
OpenManage Server Administrator (OMSA) is installed on the target server, the components are updated using OMSA.
If OMSA is not installed on the target server, the components are updated through the operating system.
271
