Remove MIB
Table 201. Remove MIB
Field Description
Imported MIB(s) Displays the list of MIBs that are imported in the OpenManage
Essentials database.
Remove MIB Click to remove the imported MIBs from the OpenManage
Essentials database.
Troubleshooting MIB Import
Issue: The Dell MIB Import displays the following error message: Dependent MIB files need to be imported. Please
import: RFC1155-SMI to the Mib Repository before continuing to import this Mib.
Cause: An MIB file may be dependent on another MIB file. While parsing a source MIB file, all the files referred by the source MIB
file must be present in the reference directory or the MIB repository. The error message is displayed because the referred MIB file is
missing from the reference directory.
Resolution: To resolve this issue:
• Ensure that you have administrator privileges in OpenManage Essentials. You must launch OpenManage Essentials at least once
before importing the MIB file.
• Retrieve the missing MIB file and add the file to the reference directory. If there are multiple dependencies of the parent MIB on
more than one file, import all the required MIB files, and then parse the parent MIB file.
NOTE: The above resolution also applies for an invalid MIB file.
Issue: Unable to parse the MIB file.
Resolution: Check the logs to see if there are any MIB compiler issues. If there are no compiler issues, compile the MIB using a
standard MIB compiler and verify whether the MIB is properly defined.
Issue: Unable to import the parsed trap definitions into OpenManage Essentials after parsing the MIB file.
Resolution: See the Readme at C:\Program Files (x86)\Dell\MIBImport for the list of MIB files that cannot be imported into
OpenManage Essentials.
Manage Traps
Custom Trap Definitions
Table 202. Custom Trap Definitions
Field Description
Add Trap
Category Name To select the event category names defined in OpenManage
Essentials or to provide a new category name.
Unknown Traps Click to display the unknown traps received in OpenManage
Essentials.
Description To provide the trap description.
Trap Name To provide or edit the trap name.
266
