Users Guide

Field Description
Category Name Displays the category name of the trap.
Severity Displays the severity of the trap. You can modify the severity of
the trap to:
• Unknown
• Info
• Normal
• Warning
• Critical
• By Value. See Severity Configuration By Value.
Format String Displays the trap description.
Enterprise OID Displays the enterprise OID (SNMP OID prefix) of the MIB file
that defines the event source that you want to monitor.
Description Displays the description of the trap.
Generic Trap ID Displays the generic trap ID of the SNMP trap that you want to
monitor from the required event source.
Specific Trap ID Displays the specific trap ID of the SNMP trap that you want to
monitor from the required event source.
Reset All Click to revert the severity of all the traps to the default values.
Import Traps Click to import traps to the OpenManage Essentials database.
Severity Configuration by Value
The Severity Configuration By Value window enables you to specify the severity of the alert based on the value of one or more
variable bindings associated with the trap.
Table 200. Severity Configuration by Value
Field Description
Trap Variable Displays the trap variable index.
Severity Displays the severity assigned for each object value or object ID.
Object ID Displays the numerical value based on the trap variable index.
Object Value Displays the string value based on the trap variable index.
Add New Click to add the severity configuration.
Select the Variable Select the trap variable that you want to update.
OK Click to save the changes.
Reset Click to revert the severity of the trap to the default values.
265
