Users Guide

Field Description
SNMP Specific Trap OID Provides the specific trap ID of the SNMP trap that you want to
monitor from the desired event source. See the Dell
OpenManage Server Administrator SNMP Reference Guide
at dell.com/OpenManageManuals for more information on
SNMP traps.
Manage MIBs
Manage MIBs Pane
The Manage MIBs pane consists of:
• Import MIB view — To import the MIB file. See Importing the MIB File.
• Remove MIB view — To remove the MIB file from the OpenManage Essentials database. See Removing the MIB File from
OpenManage Essentials.
Manage Traps Pane
The Manage Traps pane consists of:
• Custom Trap Definitions view — To add trap definitions to OpenManage Essentials database. See Adding Traps.
• Reset Built-in Trap Definitions view — To reset a pre-defined trap that you edited. See Reverting Traps.
Import MIB
Table 199. Import MIB
Field Description
Select files for upload Displays the MIB files that you have selected for upload.
Select the MIB File Displays the path of the file selected for parsing.
Browse Click to navigate to the file location.
Event Details
Category Name Select to display the event category names defined in
OpenManage Essentials and the category name of the parsed
MIB.
Severity Select to display the severity defined in OpenManage
Essentials.
Apply the selected event category to all traps Select to change the category name of all the traps.
NOTE: If you do not select the check box, you have to
manually select the traps and select the category name
from the drop-down list.
Apply the selected severity to all traps Select this check box to change the severity of all the traps.
NOTE: If you do not select the check box, you have to
manually select the traps and select the severity from
the drop-down list.
Traps Available for Import
Name Displays the trap name from the MIB file.
264
