– Chassis Templates
* Sample - VRTX Chassis
* Sample - M1000e Chassis
• Tasks — Displays the tasks of the selected category in the Tasks tab in the right pane.
– Configuration Tasks
* Chassis Configuration Import — Displays the Create Template tasks you have created for chassis.
* Device Configuration Import — Displays the Create Template tasks you have created for servers.
NOTE: For information on the sample device configuration templates, see the iDRAC documentation at dell.com/
support/manuals.
Related links
Device Compliance
Tasks
Task Execution History
Associate Devices To Template Wizard
Configuration Inventory Schedule Wizard
Device Compliance
The Device Compliance graph and table enable you to view the compliance status of the devices.
Device Compliance Graph
The device compliance graph provides a pie chart distribution of the compliance status. Click a segment of the pie chart to view
more information on the systems. The pie chart displays the following segments to indicate the device compliance status:
• Compliant — Devices that are compliant to the associated configuration template.
• Non Compliant — Devices that are not compliant to the associated configuration template.
• Non Inventoried — Devices on which configuration inventory is not completed.
• Non Associated — Devices that are not associated to a configuration template.
• Non Licensed — Devices that do not have the OpenManage Essentials — Server Configuration Management license installed.
Device Compliance Table
The fields displayed in the Device Compliance table of the Device Compliance portal are described in the following table.
Table 138. Device Compliance Table
Field Description
Compliance Status Displays an icon that indicates the compliance status of the
device to the associated configuration template.
Device Name Displays the unique name of the system that identifies it on the
network.
Service Tag Displays the unique identifier assigned to the system.
Model Displays the model name of the system. For example,
PowerEdge R710.
208
