Viewing the Device Configuration Inventory
You can view the configuration inventory of a device through the Devices portal.
Before you begin, ensure that the device for which you want to view the configuration inventory, meets the requirements specified
in
Device Requirements for Deployment and Compliance Tasks.
To view the configuration inventory:
1. Click Manage → Devices.
The Devices portal is displayed.
2. On the device tree, right-click the device for which you want to view the configuration inventory details, click Device
Configuration → Refresh Device Configuration Inventory.
3. On the right pane, click Configuration → Inventory.
The inventory configuration details are displayed. If the inventory configuration task has not been run for the device, the Run
Configuration Inventory button in is displayed. You can click Run Configuration Inventory to view the configuration details,
provided you have configured the credentials of the device in the Inventory Configuration Schedule.
Related links
Device Requirements for Deployment and Compliance Tasks
Viewing the Device Compliance Status
Before you can view the compliance status of a device to an associated configuration template, you must run the device
configuration inventory task. To run the device configuration inventory task, you can either create an inventory configuration
schedule or select the device in the device tree and click Run Configuration Inventory on the Configuration tab in the right pane.
NOTE: Compliance tasks are not supported for IOA templates.
To view the compliance status of devices to the associated configuration template:
1. Click Manage → Configurations → Device Compliance Portal.
The Device Compliance graph and grid display the compliance status of the devices.
2. To view the devices by compliance status, click the Device Compliance graph.
3. To view the compliance status of a particular device, click the device in the Device Compliance grid.
NOTE: You can also select the device in the device tree (Manage → Devices), and click the Configuration tab in the
right-pane to view the compliance status.
Viewing the Compliance Tasks
To view the compliance tasks that have been created:
1. Click Manage → Configuration.
2. In the Tasks pane on the left, select a task type.
The Task tab on the right pane displays the tasks that have been created.
NOTE: Compliance tasks are not supported for IOA templates.
Related links
Tasks
206
