Getting Started for Device Configuration Compliance
Before you can verify the compliance status of devices to a device configuration template, you must:
1. Configure the deployment file share on the server running OpenManage Essentials.
2. Configure the credentials and inventory schedule for target devices.
Related links
Configuring the Deployment File Share
Configuring the Credentials and Device Configuration Inventory Schedule
Device Configuration Compliance Overview
Device Configuration Compliance Overview
The steps that you must perform to verify the compliance status of a device and to make a device compliant to a device
configuration template are as follows:
1. Create a device configuration template — Use the Create Template task in the Common Tasks pane to create a device
configuration template. You can choose to create the template from either a configuration file or a reference device.
2. Associate a device configuration template to target devices — Select a template and associate it to applicable devices to
view the compliance status.
3. View the compliance status — The Device Compliance Portal displays the compliance summary of all devices associated to
templates. To view the compliance status of a device to an associated template, select the template in the Templates pane.
To view the detailed compliance results for each device, double-click the Device Compliance graph or table. Alternatively, you
can also select the device in the device tree (Manage → Devices), and click the Configuration tab in the right-pane to view
the compliance status.
4. Make devices compliant with the associated device configuration template (Optional) — If you want to make a device
compliant to the associated device configuration template, you must deploy the device configuration template through the
Deployment Portal.
Related links
Getting Started for Device Configuration Compliance
Configuring the Credentials and Device Configuration Inventory
Schedule
The Configuration Inventory Schedule task enables you to collect an inventory of the device configuration attributes from
applicable devices at periodic intervals. The inventory information is used to verify the compliance status of the devices to a specific
device configuration template.
Before you configure the device inventory schedule, ensure that:
• The target devices meet the requirements specified in Device Requirements for Deployment and Compliance Tasks.
• The OpenManage Essentials — Server Configuration Management license is installed on all target servers. For more
information, see OpenManage Essentials — Server Configuration Management License.
NOTE: Scheduled configuration inventory collection or update is not applicable for IOAs.
To configure the device configuration inventory schedule:
1. Click Manage → Configurations.
2. Perform one of the following:
• In the Common Tasks pane, click Configuration Inventory Schedule.
• In the Device Configuration Compliance Portal pane, click Getting Started for Compliance → Configure Credentials and
Inventory Schedule for Target Devices.
204
