Field Description
Attribute Name Displays the name of the attribute.
Value Displays the value of the attribute.
Related links
Replace Server Wizard
Options
The Options page allows you to select your preferences for the server replacement task.
The fields displayed on the Options page of the Replace Server Wizard are described in the following table.
Table 130. Options
Field Description
Remove source from compute pool Select to move the source server from the compute pool to the
Repurpose and Bare Metal Devices group after the server is
replaced.
NOTE: If this option is not selected, the source server is
retained within the compute pool after the server is
replaced.
Deploy to target even if virtual identities cannot be reclaimed
from the source
Select to reclaim the virtual I/O identities of the source server,
even if the server is unreachable.
NOTE: If the source server is not reachable and this
option is:
• Not selected — The replace server task is
unsuccessful.
• Selected — You may notice servers with duplicate I/O
identities on the network, if the source server is added
back to the network.
Related links
Replace Server Wizard
Credentials
The Credentials page allows you to provide the credentials of the source server and target server.
The fields displayed on the Credentials page of the Replace Server Wizard are described in the following table.
Table 131. Credentials
Section Field Description
Source Credentials User Name Provide the user name of the iDRAC of
the source server.
Password Provide the password of the iDRAC of
the source server.
Target Credentials User Name Provide the user name of the iDRAC of
the target server.
Password Provide the password of the iDRAC of
the target server.
Related links
Replace Server Wizard
198
