Field Description
Value Displays the value of the attribute.
Dependencies Displays if the attribute is dependent on any other attributes. To
edit a dependent attribute, you must first set the primary
attribute.
Destructive Displays if deploying the attribute may result in destructive
changes to the device configuration including performance,
connectivity, and ability to boot the device.
Undo Click to undo the changes made to the configuration template.
Save Click to save the changes to the configuration template.
Import/Export Displays the Import/Export Device Specific Attributes
window.
Import/Export Device Specific Attributes
The fields displayed on the Import/Export Device Specific Attributes window are described in the following table.
Table 115. Import/Export Device Specific Attributes
Field Description
Export Selected Device Click to export the device specific attributes for the selected
device to a .csv file.
Export All Devices Click to export the device specific attributes for all selected
devices to a .csv file.
Import Click to import the device-specific attributes.
File Requirements and Info Displays the requirements of the .csv file you must use to
import device-specific attributes.
View Logs Displays the user interface logs.
Close Click to close the Import/Export Device Specific Attributes
window.
Identity Attributes
The fields displayed on the Identity Attributes tab are described in the following table.
Table 116. Identity Attributes
Field Description
Attributes for Template Displays the selected device configuration template.
Grouped by Displayed if you choose to display the attributes as groups. By
default, the attributes are grouped by Section.
Total Displays the total number of attributes.
Modified Displays the number of attributes that you have modified.
Deploy Select to deploy an attribute. If an attribute is not selected, the
attribute value will not be deployed on the target device and the
current value will be retained on the target device. You can
select all the attributes in the template by selecting the check
box on the Deploy column header.
190
