Table 111. Select Virtual I/O Pool
Field Description
User-defined I/O assignment Select to manually assign the virtual I/O identities.
Automatic I/O assignment Select to allow OpenManage Essentials to automatically assign
virtual I/O identities to the target servers. The virtual I/O
identities are assigned from the virtual I/O pool that you select.
NOTE: The virtual I/O pools are available for selection
only if you have already created the virtual I/O pools.
Related links
Create Compute Pool Wizard
Import Service Tags/Node IDs
The Import Service Tags/Node IDs page of the Setup Auto Deployment wizard displays the Import button. Click Import to import
a .csv file that includes Service Tags or node IDs of devices that you will discover later.
NOTE: On devices which have multiple compute nodes (such as the PowerEdge FM120x4), all of the compute nodes
have the same Service Tag. Therefore, the node ID must be used to identify the specific compute node to use. In
the .csv file, you must include the node IDs of the specific compute nodes that you want to auto deploy.
NOTE: The Service Tags or node IDs that you want to import:
• Must be listed in the .csv file in a column titled ‘ServiceTag’, ‘Service Tag’, or ‘Node ID’.
• Must be valid Service Tags or node IDs.
• Must not be Service Tags or node IDs of devices that are already discovered.
The following is an example of the .csv file format that contains Service Tags and node IDs:
Figure 27. Sample CSV file
Edit Attributes
The Edit Attributes page enables you to edit the attributes of the selected configuration template, device-specific attributes, and
the IOA VLAN attributes.
NOTE: The Edit Attributes page is only displayed if you select the Deploy Template option in the Name and Deploy
Options or Deploy Options page.
Template Attributes
NOTE: The Template Attributes tab will not be displayed if you select the IOA Template option for deployment.
The fields displayed in the Template Attributes tab of the Edit Attributes page are described in the following table.
187
