Field Description
Password Provide the IOA administrator password required to deploy the
VLAN attributes.
Related links
Deploy Template Wizard
Preview
NOTE: The preview activity is optional.
The Preview page allows you to view the attributes of the selected configuration template that will not be applied successfully on a
target device. The preview activity sends the pending configuration to each target device, but for validation only (no configuration
changes are made). Each device verifies the validity of the settings in the configuration and identifies any problems. The verification
can identify problems with attribute values themselves, or problems based on inter-attribute dependencies. For example, creating a
device configuration template from a PowerEdge R720 server and deploying the template on a PowerEdge R620 server would
result in errors. Running the preview allows you to identify the attributes that will not be deployed successfully. After identifying
those attributes, if required, you can clear those attributes from the template and then deploy the template.
NOTE: The preview activity identifies many problems; however, some problems cannot be determined before the actual
deployment.
Click the Preview button to validate the attributes of the device configuration template with the selected device.
Related links
Deploy Template Wizard
Summary
The Summary page displays the options you have selected for the deployment task.
The fields displayed in the Summary page are described in the following table.
Table 107. Summary
Field Description
Task Name Displays the task name.
Deploy Template Displays if the task will deploy a configuration template.
Boot to Network ISO Displays if the task will boot to a network ISO image.
Deploy Target Displays the target devices that you have selected.
Selected Template Displays the configuration template selected for deployment.
Device Specific Attributes Displays if the device-specific attributes are set.
ISO Filename Displays the name of the ISO file.
Share IP Displays the IP address of the network share where the ISO file
is available.
Share Name Displays the name of the network share where the ISO file is
available.
Share Username Displays the user name provided to access the network share.
Identity Assignment Displays the type of I/O identity assignment that you have
selected.
184
