Field Description
Deploy Select to deploy an attribute. If an attribute is not selected, the
attribute value will not be deployed on the target device and the
current value will be retained on the target device. You can
select all the attributes in the template by selecting the check
box in the Deploy column header.
Modified Displays if you have modified the attributes.
NIC Displays the Fully Qualified Device Descriptor (FQDD) of the
NIC.
Fabric Displays the fabric associated with a specific slot of the chassis.
The fabric is identified by a combination of the group name (A,
B, or C) and slot number (1 or 2).
Tagged VLAN(s) Displays the list of tagged VLANs for the selected fabric.
Untagged VLAN Displays the untagged VLAN for the selected fabric.
Undo Click to undo the changes made to the IOA VLAN attributes of
the selected template.
Save Click to save the changes to the IOA VLAN attributes of the
selected template.
Device Specific Attributes
The fields displayed on the Device Specific Attributes tab are described in the following table.
Table 101. Device Specific Attributes
Field Description
Select Devices Displays the devices that you have selected for deployment.
You can select a device to view the attributes specific to that
device.
Device Specific Attributes for Displays the model number and Service Tag of the selected
device.
Grouped by Displayed if you have chosen to display the attributes as groups.
Total Displays the total number of attributes.
Modified Displays the number of attributes that you have modified.
Deploy Select to deploy an attribute. If an attribute is not selected, the
attribute value will not be deployed on the target device and the
current value will be retained on the target device. You can
select all the attributes in the template by selecting the check
box in the Deploy column header.
Modified Displays if you have modified the value of the attribute.
Section Displays the component that the attribute belongs to. For
example, iDRAC, BIOS, NIC, and so on.
Instance Displays the instance of the component that the attribute
belongs to.
Attribute Name Displays the name of the attribute.
180
