Table 89. Identity Attributes
Field Description
Attributes for Template Displays the selected device configuration template.
Grouped by Displayed if you choose to display the attributes as groups. By
default, the attributes are grouped by Section.
Total Displays the total number of attributes.
Modified Displays the number of attributes that you have modified.
Deploy Select to deploy an attribute. If an attribute is not selected, the
attribute value will not be deployed on the target device and the
current value will be retained on the target device. You can
select all the attributes in the template by selecting the check
box on the Deploy column header.
Modified Displays if you have modified the value of the attribute.
Identity Impact Displays if the identity attribute will be automatically generated.
Status Displays the status of the generation of the identity attribute.
An Error status is displayed if the selected virtual I/O pool
either does not contain the virtual I/O attribute or does not
have sufficient attributes.
Section Displays the component that the attribute belongs to. For
example, iDRAC, BIOS, NIC, and so on.
Instance Displays the instance of the component that the attribute
belongs to.
Attribute Name Displays the name of the attribute.
Value Displays the value of the attribute.
Dependencies Displays if the attribute is dependent on any other attributes. To
edit a dependent attribute, you must first set the primary
attribute.
Destructive Displays if deploying the attribute may result in destructive
changes to the device configuration including performance,
connectivity, and ability to boot the device.
Group Displays the logical group that the attribute belongs to.
Assign Identities Click to automatically assign virtual I/O identities to the target
devices.
Undo Click to undo the changes made to the configuration template.
Save Click to save the changes to the configuration template.
Import/Export Displays the Import/Export Device Specific Attributes
window.
Identity Assignments
The fields displayed on the Identity Assignments tab are described in the following table.
NOTE: The Identity Assignments tab is displayed only when you click Assign Identities on the Identity Attributes tab.
173
